We machined aluminum with an all-round cutter! #cnc #machine #engineering
↓Long version!↓
DoMultiRec
■Products :
Tool : EVLX12M025C25.0R02
https://catalog.tungaloy.com/Item.aspx?cat=6799041&fnum=2583&mapp=ML&GFSTYP=M&srch=1
Insert : LXGU120404PFR-AM KS05F
https://catalog.tungaloy.com/item.aspx?cat=7742832&fnum=2839&mapp=ML&app=0&Lang=JP&GFSTYP=M&isoD=1
■Cutting conditions :
①［Slotting / Shoulder］
Vc = 700 m/min, fz = 0.1 mm/t, ap = 6.0 mm, ae = 25 mm
(Shoulder = 15 mm)
②［Helical］
Vc = 700 m/min, fz = 0.1 mm/t, DC = 14 mm, ae = 25 mm
③［Plunging］
Vc = 700 m/min, fz = 0.01 mm/t, ap = 28 mm, ae = 12.5 mm
④［Hole making / Slotting］
Vc = 700 m/min, fz = 0.1 mm/t (Slotting =0.03 mm) , DC = 5.0 mm, ae = 25 mm
■Work material : ADC12
■Machine : BT50
