If you feel that BT30 machines have limited machining range, this is worth a look. By shortening tool overhang, the machining range can expand significantly 📈
↓ See the reason behind it and the comparison data here 👇

#30-SPINDLE Isn’t the Limitation. Tool Overhang Is.

■Product：TungMeister, TungShort

■Product Information
Tool : BT30ER20SHORT
https://catalog.tungaloy.com/Item.aspx?cat=4504056&fnum=398&mapp=IT&GFSTYP=m&srch=1

Colette : VER20AL004S10-S
https://catalog.tungaloy.com/Item.aspx?cat=6967142&fnum=2106&mapp=IT&GFSTYP=m&srch=1

Head : VEE160L12.0C40R05S10 AH715
https://catalog.tungaloy.com/Item.aspx?cat=6779138&fnum=56&mapp=ML&GFSTYP=m&srch=1

Wrench : WRENCH ER20 SHORT RING22
https://catalog.tungaloy.com/Item.aspx?cat=4504323&fnum=1351&mapp=IT&GFSTYP=m&srch=1

Spanner for head : KEYV-S10
https://catalog.tungaloy.com/Item.aspx?cat=4504323&fnum=1351&mapp=IT&GFSTYP=m&srch=1

■Cutting Condition
S45C / Slotting / DRY
Vc = 140 m/min
fz = 0.05 mm/t
Vf = 696 mm/min
ap = 10 mm
ae = 16 mm
n = 2785 min⁻¹
Z = 5

SUS304 / Slotting / WET
Vc = 140 m/min
fz = 0.03 mm/t
Vf = 418 mm/min
ap = 10 mm
ae = 16 mm
n = 2785 min⁻¹
Z = 5

Inconel 718 / Slotting / WET
Vc = 40 m/min
fz = 0.02 mm/t
Vf = 80 mm/min
ap = 10 mm
ae = 16 mm
n = 796 min⁻¹
Z = 5

■Material
S45C / C45 / 1045
SUS304 / X5CrNi18-10 / 304
Inconel 718 / NiCr19Fe19Nb5Mo3 / N07718

■Machine
Machining Center / FANUC α-T14iFa (BBT30, 12.5/3.7kW, 10,000 min⁻¹, Table Size: X650 Y400)

For more information, please contact us!
