Pipe bracket bending machine#cnc #machine #bending #pipeclamp
Pipe bracket bending machine: Bending, cutting, punching, marking, feeding, and leveling—an essential machine for manufacturing pipe clamps.
Advantages: Capable of producing various shapes and specifications on a single machine.
This channel covers machine installation, programming, operation, and maintenance.
Pipe bracket bending machine specifications:
Control system: PLC
Feeding: Servo motor
Bending: Servo motor
Cutting, punching, and marking: Hydraulic system
Model: 50*5mm
Processing thickness range: 0–5mm
Processing width range: 0–50mm
Processing diameter range: 25–600mm
Bending servo motor: 3.8kW (1 unit) with planetary gearbox; high bending precision
Feeding servo motor: 3.8kW (1 unit) with planetary gearbox; high feeding precision
Telescopic servo motor: 1.0kW (1 unit) with planetary gearbox; high telescopic precision
Hydraulic system: 15kW with air-cooling system; high power and fast operation speed
Machine Model: 60×6mm
Processing Thickness Range: 0–6mm
Processing Width Range: 0–60mm
Processing Diameter Range: 25–600mm
Bending Servo Motor: 5.5kW (1 unit) with planetary gearbox; high bending precision
Feeding Servo Motor: 5.5kW (1 unit) with planetary gearbox; high feeding precision
Extension/Retraction Servo Motor: 1.0kW (1 unit) with planetary gearbox; high extension precision
Hydraulic System: 15kW + air cooling system; high power and fast speed
Machine Model: 70×7mm
Processing Thickness Range: 0–7mm
Processing Width Range: 0–70mm
Processing Diameter Range: 50–600mm
Bending Servo Motors: 5.5kW (2 units) with planetary gearboxes; high bending precision
Feeding Servo Motor: 5.5kW (1 unit) with planetary gearbox; high feeding precision
Extension/Retraction Servo Motor: 1.0kW (1 unit) with planetary gearbox; high extension precision
Hydraulic System: 15kW + air cooling system; high power and fast speed
Machine Model: 80×8mm
Processing Thickness Range: 0–8mm
Processing Width Range: 0–80mm
Processing Diameter Range: 100–600mm
Bending Servo Motors: 5.5kW (2 units) with planetary gearboxes; high bending precision
Feeding Servo Motor: 7.5kW (1 unit) with planetary gearbox; high feeding precision
Extension/Retraction Servo Motor: 1.0kW (1 unit) with planetary gearbox; high extension precision
Hydraulic System: 15kW + air cooling system; high power and fast speed
If you are interested in bending, punching, and machining, please subscribe!
We offer custom machinery and sample production services.
Feel free to contact us if you have any questions.
WhatsApp: +86 15383942336
Email: ji*************@***il.com
