The combination of a Φ8 TungMeister VVFH head and TungShort creates a compact setup with reduced overhang. Using just one head, we efficiently machined four hole sizes (Φ8, Φ10, Φ12, and Φ14) on S50C.
↓New ER32 Size！
ヘッド交換式エンドミル『TungMeister』 ERコレット一体型シャンクにER32サイズを追加 ― クーラント穴付き一体構造で旋盤・複合加工機の加工信頼性を向上 ―
■ Product : TungMeister (VVFH), TungShort
■ Product Information
Tool : BT30 ER20 SHORT
https://catalog.tungaloy.com/Item.aspx?cat=4504056&fnum=398&mapp=IT&GFSTYP=M&srch=1
Head : VER20AL004S05-S
https://catalog.tungaloy.com/Item.aspx?cat=6967137&fnum=2106&mapp=IT&GFSTYP=M&srch=1
Insert : VVFH0800S03R04S05 AH715
https://catalog.tungaloy.com/Item.aspx?cat=7755281&fnum=2964&mapp=ML&GFSTYP=M&srch=1
■ Cutting Conditions
[Φ8 — Plunge drilling]
Vc (m/min) : 150
fz (mm/t) : 0.04
Pitch (mm) : —
Depth (mm) : 5
No. of teeth : 3
[Φ10, Φ12, Φ14 — Helical milling]
Vc (m/min) : 200
fz (mm/t) : 0.15
Pitch (mm) : Φ10・Φ12(1.5) Φ14(2.0)
Depth (mm) : 5
No. of teeth : 3
■ Material : S50C / C50 / 1050
■ Machine : ROBODRILL
